ISM: Lösungen für sensible, drahtlose Anwendungen
ISM (Industrial, Scientific, Medical) steht für Hochfrequenzgeräte in Industrie, Wissenschaft und Medizin. Dieser Bereich hat aus Sicherheitsgründen seine eigenen Frequenzen. Inzwischen werden die ISM-Bänder aber auch für viele andere Funkübertragungssysteme mit geringer Sendeleistung (z. B. Fernbedienungen) genutzt. Aufgrund dieser vielfältigen Anwendungsbereiche sind die Anforderungen an die Hersteller sehr hoch.
UNITRONIC Electronics kooperiert mit Radiocrafts und NeoCortec, die auf dem ISM-Gebiet ausgewiesene Experten mit langjähriger Erfahrung sind.
ArtikelNr. | Bild | Bezeichnung | Verfügbarkeit | Add to Cart Button | Kurzbeschreibung | Hersteller | Datenblatt | FREQUENZ | INTERFACE | Technologie | TEMPERATUR | VERSORGUNG | Messbereich | VERBRAUCH |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
23185 |
![]() |
RC1180-MBUS3-USB Radiocrafts | Auf Anfrage | Weiterlesen | The USB-sticks from Radiocrafts are designed to provide an easy to use network node for development, prototyping or simple networks. |
RADIOCRAFT |
868 |
USB |
Wireless M-Bus |
|
|
|
| |
22266 |
![]() |
NC2400 NeoCortec | Vorrätig | 2.4GHz NEOCORTEC Compliant Transceiver enabling ultra-low-power bi-directional wirelessmulti-hobmesh network communication |
NEO |
|
2,4 |
UART, GPIOs |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
0,5µA | |
22269 |
![]() |
NC1000 NeoCortec 868MHz SRD | Auf Anfrage | Weiterlesen | Dual band 868/915MHz NEOCORTEC Compliant Transceivenabling ultra-low-power bi-directionalwireless multi-hob mesh network communication |
NEO |
|
868 |
uart |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
|
22298 |
![]() |
Eval Kit NC2400 2,4 GHz | Vorrätig |
|
NEO |
|
2,4 |
uart |
|
|
|
|
| |
23607 |
![]() |
RC1180-KNX2 Radiocrafts RF Modul with embedded | Auf Anfrage | Weiterlesen | The RC1180-KNX2RF Transceiver Module is a compact surface-mounted high performance module with embedded Wireless M-Bus protocol. |
RADIOCRAFT |
868 |
uart |
KNX RF |
-40°C .. +85°C |
2,0 VDC .. 3,9 VDC |
|
| |
23608 |
![]() |
RC2400-ZNM Radiocrafts RF Module ZNM Zigbee | Auf Anfrage | Weiterlesen |
|
RADIOCRAFT |
2,4 |
uart, SPI |
ZigBee |
-30°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| |
23658 |
![]() |
RC1880CEF-GPR | Auf Anfrage | Weiterlesen | The RC1880-GPR is a sub-1 GHz co-processormodule for RIIoT (Radiocrafts IndustrialInternet of Things) gateways. It interfaces |
RADIOCRAFT |
868 |
|
RIIOT |
-40°C .. +85°C |
1,8 VDC .. 3,8 VDC |
|
| |
23651 |
![]() |
RC1181HP-TM | Auf Anfrage | Weiterlesen | Tinymesh(TM) RF Transceiver Moduleswireless mesh networking applicationmulti-hop protocol stack |
RADIOCRAFT |
|
868 |
uart |
|
-40°C .. +85°C |
3,0 VDC .. 3,3 VDC |
|
|
23652 |
![]() |
RC1701HP-WIZE | Auf Anfrage | Weiterlesen | The RC1701HP-WIZE is part of a compact surface-mounted Wireless M-Bus module family thatmeasures only 12.7 x 25.4 x 3.7 mm. |
RADIOCRAFT |
169 |
uart |
WIZE |
-30°C .. +85°C |
2,8 VDC .. 3,6 VDC |
|
| |
23653 |
![]() |
RC1701HP-MPC1 | Auf Anfrage | Weiterlesen | The MPC1 Wireless M-Bus moduleis a stand-alone Wireless M-Bus module withPulse counter, Tamper and Installinputs. The module communicates |
RADIOCRAFT |
169 |
3x pulse input |
Wireless M-Bus |
|
|
|
| |
23654 |
![]() |
RC1180-MSM | Auf Anfrage | Weiterlesen | The RC1180-MSMmodule is a fully integrated, autonomous sensor-enabled, compact surfacemounted product that measures only |
RADIOCRAFT |
868 |
I2C, SPI, Analog, and Digital GPIOs |
Wireless M-Bus |
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| |
23657 |
![]() |
RC1880CEF-SPR | Auf Anfrage | Weiterlesen | The RC1880-SPRis a sub-1 GHz programmable ultra-low power module for RIIoT(Radiocrafts Industrial Internet of Things). It isbased on the open |
RADIOCRAFT |
868 |
|
RIIOT |
-40°C .. +85°C |
1,8 VDC .. 3,8 VDC |
|
| |
22861 |
![]() |
RC1180-MPC1 Wireless M-Bus | Vorrätig | Wireless M-Bus RF Transceiver Module(EN 13757-4:2013) with Pulse Counter inputsembedded WMBus protocol |
RADIOCRAFT |
868 |
uart, pulse counter |
Wireless M-Bus |
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| ||
22911 |
![]() |
RC1701VHP-MBUS4 Radiocrafts | Vorrätig | Wireless M-Bus High power N Mode RF TransceiverEN 13757-4:2013embedded WMBus protocol |
RADIOCRAFT |
169 |
uart |
|
-30°C .. +85°C |
2,8 VDC .. 3,6 VDC |
|
| ||
22631 |
![]() |
RC1240 Modul RC232 - Ultra Narrow Band EU | Auf Anfrage | Weiterlesen | Narrow BandMulti-Channel RF Transceiver ModuleLow power, high performance embedded protocol |
RADIOCRAFT |
433 |
uart |
ISM proprietär |
-20°C .. +55°C |
2,8 VDC .. 5,5 VDC |
|
| |
22642 |
![]() |
RC1180-MBUS3 | Auf Anfrage | Weiterlesen | Wireless M-Bus Multi-Mode RF Transceiver Module(EN 13757-4:2013)embedded WMBus protocol |
RADIOCRAFT |
868 |
uart |
Wireless M-Bus |
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| |
22657 |
![]() |
RC1682-SIG 868 MHz | Auf Anfrage | Weiterlesen | High Performance RF Module for SIGFOX 868MHzembedded SIGFOX protocolconforms with EU RED |
RADIOCRAFT |
868 |
uart |
|
-30°C .. +85°C |
2,8 VDC .. 3,6 VDC |
|
| |
22685 |
![]() |
RC1780HP-TM | Vorrätig | Tinymesh(TM) RF Transceiver Moduleswireless mesh networking applicationmulti-hop protocol stack |
RADIOCRAFT |
|
868 |
uart |
|
-30°C .. +85°C |
2,8 VDC .. 3,6 VDC |
|
| |
22713 |
![]() |
RC1180HP-RC232 (MOQ 10 pieces) | Auf Anfrage | Weiterlesen | High PowerMulti-Channel RF Transceiver ModuleRS232/422/485 wire replacementembedded protocol |
RADIOCRAFT |
868 |
uart |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| |
22715 |
![]() |
RC1141-TM | Auf Anfrage | Weiterlesen | Tinymesh(TM) RF Transceiver Moduleswireless mesh networking applicationmulti-hop protocol stack |
RADIOCRAFT |
|
433 |
uart |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
|
22716 |
![]() |
RC1181-TM | Auf Anfrage | Weiterlesen | Tinymesh(TM) RF Transceiver Moduleswireless mesh networking applicationmulti-hop protocol stack |
RADIOCRAFT |
|
868 |
uart |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
|
22742 |
![]() |
RC1780HP-RC232 (MOQ 10 pieces) | Vorrätig | Ultra Narrow BandHigh Power RF Moduleembedded protocolconforms with EU RED |
RADIOCRAFT |
868 |
uart |
|
-30°C .. +85°C |
2,8 VDC .. 3,6 VDC |
|
| ||
22842 |
![]() |
RC1140-RC232 Radiocrafts | Auf Anfrage | Weiterlesen | Low Cost Multi-Channel RF Transceiver ModuleRS232/422/485 wire replacementembedded protocol |
RADIOCRAFT |
433 |
uart |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| |
22843 |
![]() |
RC1180-RC232 Radiocrafts | Auf Anfrage | Weiterlesen | Low Cost Multi-Channel RF Transceiver ModuleRS232/422/485 wire replacementembedded protocol |
RADIOCRAFT |
868 |
uart |
|
-40°C .. +85°C |
2,0 VDC .. 3,6 VDC |
|
| |
22852 |
![]() |
RC1280 Ultra Narrow Band | Auf Anfrage | Weiterlesen | Narrow BandMulti-Channel RF Transceiver ModuleLow power, high performance embedded protocol |
RADIOCRAFT |
868 |
uart |
|
-20°C .. +55°C |
2,8 VDC .. 5,5 VDC |
|
| |
22854 |
![]() |
RC1701HP- RC232 Ultra Narrow | Vorrätig | Ultra Narrow BandHigh Power RF Modulehigh power, long rangeembedded protocol |
RADIOCRAFT |
169 |
uart |
|
-30°C .. +85°C |
2,8 VDC .. 3,6 VDC |
|
|
